MJP19 LCD Graphic Monitor Tablet

Products List:
	MJP19

MJP-19 19 inch WideScreen 16:10 LCD Monitor Famous Japanese Graphic Tablet brand "P-Active" has great success on Pen Tablet market. And now with these great graphic tablet technologies we are announcing the perfect tool for graphic creation. The MJP-19, 19 inches with 2048 high pressure sensitivity level, with flexible stand display angle from 16 degrees to 75 degrees. XP-PEN is a new standard in graphic tablets, top quality tablet at an affordable price. These tablets are ideal for professionals and students in the digital art industries. Handwriting recognition on your MAC or PC allows for digital signatures on documents and personalized emails. The Graphic Tablet is a computer input device that allows one to hand-draw images and graphics, similar to the way one draws images with a pencil and paper. These tablets may also be used to capture data or handwritten signatures. It can also be used to trace an image from a piece of paper which is taped or otherwise secured to the surface. Capturing data in this way, either by tracing or entering the corners of linear poly-lines or shapes is called digitizing. Graphic Tablet consists of a flat surface upon which the user may "draw" or trace an image using an attached stylus, a pen-like drawing apparatus. It is also called pen pad or digitizer The image generally does not appear on the tablet itself but, rather, is displayed on the computer monitor. Some tablets, however, come as a functioning secondary computer screen that you can interact with images directly by using the stylus. Fully support Windows 7 applications. Don’t you want to try the best build-in application of Windows 7 instead of use traditional mouse?

Features

Education: Natural pen feel allows kids to enjoy e-learning easier at School or Home. Do lots of fun things like drawing, writing, sketching, coloring, and editing photos.
Animate / Video Effects: Assist in editing video, music and animation. Works fast and works great with professional software.
Business: Great for presentations, seminars, and panel discussions. Write, sketch, circle, or add notes during your presentation to emphasize important points.
Artists: Great for package design, illustration, advertising, and Web Design. Sketch, color, paint, and edit work with professional software.

Specfication

Model	MJP19
Display
Screen size	19" diagonal
Backlight	LED
Aspect Ratio	16:10
Display area（H x V）	408.24 x 255.15 mm， 19 inch (diagonal)
Native resolution	1440 x 900
Pixel pitch (H x V)	0.2835 x 0.2835 mm
Brightness (typical)	250cd/㎡
Contrast ratio (typical)	1000:1，dynamic 50000:1
Response time (typical)	5 ms
Viewing angle（typical）	H:85°/85°, V: 80°/80°， @ CR ≥ 10
Number of colors	16.7M
Color management	ICC profile, 6500° K whitepoint default
Tablet
Interactive method	Electromagnetic resonance method
Resolution	4000 LPI (lines per inch)
Tracking speed	Approximately 130 points per second
Reading accuracy	Center ± 0.5 mm
Pen pressure sensitive	2048 levels
Pen detectable height	10mm (between pen tip and glass surface)
Pen detectable tilt	±45 degree (vertical pen angle)
Data communication	mini-USB interface
Pen battery	AAA alkaline dry cell x 1
OS support	Windows 7/Vista/XP, MAC OS 10.2.8 or above
Application Software(free)	Office Ink, Free Notes, MyScript Stylus (Win7/XP/2000)
	Power Presenter REII, (Win XP/2000)
ExpressKeys	N/A
Pen Power Consumption	700uA (Max.)
Power supply
Horizontal & Vertical Frequency	H:30~ 81 kHz;V:56 ~ 75 Hz
Pixel frequency	140 MHz
Video signal input (R/G/B)	0.7 Vpp / 75 ohms ( analog video signals )
Syns signal (TTL level)	LH: 2.0 ~ 5.0 Vpp, LL: 0 ~ 0.8 Vpp
Type	External adapter
Monitor DC input	12VDC 3A
Power adapter in/out	input 100-240VAC 50/60Hz, output 12VDC 3A
power consumption	max:20 watts;saving:<1w;off<0.5w
Connections
VGA in	undetachable, with a 1.5m 15pin D-sub & Dc-in 2 in 1 cable
USB	USB x1 (cable attached)
VGA out	15-pin D-sub ( in back side )
User control
Control type	OSD / 5 keys
Factory preset modes	720 x 400 @ 70Hz,640 x 480 @ 60Hz/72Hz/75Hz
	800 x 600 @ 60Hz/72Hz/75Hz,1024x 768 @60Hz/70Hz/75Hz
	1280 x 1024@ 60Hz/75Hz
	1440x900@ 60Hz/75Hz
OSD Language	16 languages (Eng/Deu/Fre/Ita/Spa/Por/Ch-s/Ch-t Pol/Rus/Kor/Dan/Dut/Fin/Swe/Jap)
Physical specs
Unit dimension（W x H x D）	476 mm x 371.5 mm x 51.2 mm
Weight	Net 4.4 kg ，gross 5.8 kg
Stand adjustability	Tilt: 5°~ 45°, 0°(0°to make it look parallel with tabletop )
VESA mounting	75 x 75 mm
Kensington lock	yes
Accessories
Pen kits package	x 1
Pen holder	x 1
Power adapter	x 1
Power cord	x 1
USB cable	x 1
User's manual	x 1
CD	x 1 (Device drivers and bundled software)
Reliability & Certificates
Temperature & Humidity	0-40°C (32-104°F), 20-80% (non-condensing)
MTBF	50,000 H
Certificates	CCC/FCC/CE/RoHS

Package Contents

Product Pictures

Shipping Weight

Item	Net weight	Dimension	Q'TY	N.W.	G.W.	MEAS
	(KGS)	(CM x CM x CM)	(PCS/CTN)	(KGS)	(KGS)	(Cuft)
XP-4026	0.38	26 x 19 x 4	40	5.6	17.5	3
XP-5560C	0.85	30 x 25 x 6	20	16	17	4
XP-6040	0.25	23 x 23 x 5
XPW-6370	0.83	30 x 25 x 6	20	13	14.2	3.72
XP-8060C	1.5	35 x 30 x 6	10	12	13	2.5
XP-P850	1.5	35 x 30 x 6	10	7	15	2.7
XP-1209B	2.2	46 x 40.5 x 6.5	10	24.7	25.7	5.65
XPC-1901W	6	57 x 50 x 17.5	2	12	13
